Abstract
In mechanical processing, in addition to the use of pressing plate clamping parts, but
also usually use magnetic chuck, pneumatic fixture and plate vacuum chuck clamping.
Pressure plate clamping, low efficiency; Magnetic chuck can not be applied to
non-ferrous and non-metallic parts; Special pneumatic fixture and plate type vacuum
chuck are expensive, poor interchangeability, but also limited by the shape of parts.
Modular magnetic vacuum chuck device combines magnetic force and va
磁力真空吸盘装置设计-4614字.pdf
